Experience industry-leading accuracy with Sensyor’s optical rotary encoders, designed for precision motion control in the most demanding environments. Our industrial-grade optical incremental encoders deliver resolutions up to 65,536 CPR, available in both incremental and absolute optical configurations.
Explore our versatile product range through an interactive image carousel featuring key shafted and hollow-shaft variants engineered for seamless integration.
Get started today — Download Datasheet or Request a Quote for tailored solutions optimized for your application.
Our optical rotary encoders deliver high-resolution optical sensing for precise position feedback. This means you get superior accuracy and repeatability, essential for demanding applications like industrial automation and servo motor control.
Choose from incremental or absolute output signals to fit your system needs. Both options support accurate motion control with noise-immune signals, including an available differential line driver for enhanced signal stability.
Our encoders come in multiple mounting configurations for easy integration:
| Mounting Type | Description | Typical Use Case |
|---|---|---|
| Servo Mount | Secure shafted installation | Precision servo motors |
| Flange Mount | Easy-to-install face mounting | CNC machines, packaging lines |
| Hollow Shaft | Direct shaft coupling | Space-saving motor feedback |
All these features combine to make Sensyor optical rotary encoders an outstanding choice for reliable, long-lasting position sensing.
Explore more about our GLS45C rotary encoder with detailed specs and mounting options.
Optical rotary encoders work by shining an LED light through a precision code disk that’s attached to the rotating shaft. Photodetectors on the other side pick up the light patterns, translating them into electrical signals representing position and movement. This optical encoding principle delivers high accuracy and repeatability.
There are two main configurations: transmissive and reflective. In the transmissive setup, the light passes through the code disk’s transparent and opaque sections. In the reflective type, the LED shines light onto a patterned surface, and the reflected light is detected. Both types offer distinct advantages depending on your application needs.
Our optical rotary encoders come in incremental and absolute output versions. Incremental encoders generate A/B quadrature signals plus an index pulse to track relative position changes, ideal for motion control that resets or tracks movements dynamically. Absolute encoders provide a unique position code for every shaft angle, perfect when precise, non-volatile positioning is required.
Compared to magnetic encoders, optical rotary encoders offer higher resolution and better immunity to electromagnetic interference (EMI), making them well-suited for precision tasks in clean and controlled environments. This makes them a reliable choice for demanding applications that require precise position feedback and consistent performance.Explore related solutions like our optical incremental shaft encoder to see how these technologies deliver efficiency and accuracy in real-world setups.
Our optical rotary encoders deliver precision and durability tailored for demanding industrial environments. Here’s a quick overview of key technical specs to guide your selection:
| Specification | Details |
|---|---|
| Resolution (CPR/PPR) | From 100 up to 65,536 CPR for both incremental and absolute outputs |
| Output Signals | TTL, HTL, open collector, differential RS422 for noise-immune signals |
| Shaft Diameter / Bore | Standard sizes: 6mm, 8mm, 10mm. Hollow shafts available up to 20mm |
| Supply Voltage | 5 V DC to 30 V DC depending on model |
| Supply Current | Typically 50 mA to 100 mA under normal operation |
| Max Rotational Speed | Up to 12,000 RPM (depend on model and output type) |
| Frequency Response | Up to 500 kHz for high-speed encoding |
| Environmental Ratings | IP64 to IP67 for dust and water resistance |
| Operating Temp. Range | -40°C to +105°C |
| Storage Temp. Range | -40°C to +120°C |
| Shock & Vibration | 100 g shock, 15 g vibration tested |
| Mechanical Housing | Anodized aluminum or stainless steel options |
| Bearing Type | High-quality ball bearings for long operational life |
| Torque | Typically <0.05 Nm |
| Weight | Ranges 80g to 150g depending on model |
| Connector Types | M12, flying leads, or custom cable assemblies |
| Cable Options | Shielded & unshielded cables, custom lengths available |
These specs make Sensyor encoders ideal for light to heavy-duty applications requiring reliable and repeatable position feedback. For precise configuration details or customized options, check our incremental rotary encoders supplier page or explore the difference between absolute and incremental encoders.
Sensyor offers a versatile range of optical rotary encoders designed to fit different industrial needs. Whether you require high-resolution precision or heavy-duty durability, we have a model for you.
| Model | Type | Resolution (CPR) | Shaft Size (mm) | IP Rating | Key Applications |
|---|---|---|---|---|---|
| GOS25C Standard | Incremental | Up to 10,000 CPR | 6, 8, 10 | IP64 | Industrial automation, robotics |
| GOS38H High-Res | Absolute/Incremental | Up to 50,000 CPR | 8, 12 | IP67 | CNC machines, servo motors |
| Heavy-Duty Series | Incremental/Absolute | Up to 40,000 CPR | 10, 15 | IP68 | Wind turbines, elevators, hoists |
For specialized needs, explore our high-resolution absolute encoder models or check out the popular incremental rotary encoders for industrial automation to find the ideal fit.
Our high-resolution optical rotary encoders are designed to excel in a wide range of demanding fields. Their precise optical position sensing and robust build make them ideal for applications such as:
These applications benefit from the superior resolution, long life, and EMI-immune performance of Sensyor’s optical rotary encoders, tailored for industrial-grade reliability. For a deeper dive, see how the incremental shaft encoder enhances precision in industrial automation.
Choosing Sensyor means opting for precision engineering you can rely on. Our optical rotary encoders deliver consistent performance, ensuring accurate position feedback for your demanding applications.
Key Advantages:
| Feature | Benefit |
|---|---|
| Precision Engineering | High-resolution optical sensing for exact motion control |
| Consistent Performance | Stable signals with noise-immune outputs |
| Competitive Lead Times | Fast delivery to keep your projects on schedule |
| Reliable Supply Chain | Steady availability for uninterrupted production |
| Industry Compliance | Meets CE, RoHS, and global standards for safety and quality |
| Comprehensive Support | Expert technical assistance, 3D models, and easy integration guides |
We back our industrial optical encoders with strong support, helping you integrate smoothly into your systems. Whether you need custom configurations or detailed installation advice, our team is here to assist.
For more on how our incremental and absolute encoder options fit your needs, check our in-depth guide on incremental rotary encoders. Find the perfect match for your application with confidence using Sensyor’s precision rotary encoder solutions.
Enhance your optical rotary encoder setup with Sensyor’s range of essential accessories designed for easy integration and optimal performance.
For added reliability and smooth installation, pair your Sensyor optical position sensors with our high-quality coupling solutions designed for shaft alignment and torque transmission needs. Check out our coupling series for detailed specifications and compatibility.
We make it easy to get your hands on everything you need for Sensyor optical rotary encoders. Access our comprehensive resource library to help you select, install, and maintain your high-resolution rotary encoders.
Having these resources ensures your optical incremental encoder or precision rotary encoder performs flawlessly from day one, backed by our expert support for any challenges.
Our Sensyor optical rotary encoders have proven their value across numerous demanding applications worldwide. Customers frequently highlight the exceptional precision and reliability of our high-resolution rotary encoders, even under tough industrial conditions.
These case studies underline the robust design and advanced optical position sensor technology that keeps Sensyor a top choice in motion control and servo motor encoder markets.
For specific application feedback and detailed performance metrics, you can explore products like our shaft encoder optical models, including the GOS63 rotary encoder known for its high-resolution and durability in harsh environments.
Explore more about our extensive range of optical rotary encoders to find the perfect fit for your application:
These categories cover the full spectrum of precision rotary position sensing, including options for both incremental and absolute output types, designed to meet the rigorous demands of industrial automation, robotics, and motion control systems. Visit our detailed pages on incremental optical encoders and high-resolution rotary encoders to learn more and select the right sensor for your needs.
