| G | 0 | S | 58 | 15 | F | 600 | L | 6 | 2M | |||
| Category of
product |
Type of product | Form of
main shaft |
Contour of
product |
Size of main
shaft,shaft hole |
Outlet and
sealing form |
Resolution | Output form | Output signal | Cable | |||
| G:incremental type | O:megneto- electricity
L:photoelec- tricity |
S:solid shaft | 58:φ58mm | 15:φ15mm
|
F:Side outlet
pug |
10,20,50,
60,100, 200,360, 400,500, 600,800, 1000,1024,1 200,2000,20 48,2500,300 0,3600,5000 |
F:complementary output
L:5V drive output |
1:phase Asignal
2:phase AB signa 3:phase ABZ signal 4:phase ABA/B/ signal 5:phase ABZA/B/Z/ signal |
Default
2m line,For non 2m, labeling is sufficient |
| Line color | Toutput signal | Line color | L/A output signal | |
| red1 | VCC | red1 | VCC | |
| black4 | GND | |||
| black4 | GND | |||
| green3 | A phase | |||
| green3 | A phase | white5 | B phase | |
| yellow2 | Z phase | |||
| white5 | B phase | |||
| brown7 | Aphase | |||
| yellow2 | Z phase | grary6 | Bphase | |
| orange8 | Zphase | |||
| shield | F ·G | |||
| shield | F ·G |
complementary output
long line drive output
