| G | 0 | S | 58 | □ | B | 1000 | A | 6 | 2M | ||||
| Category of
product |
Type of product | Form of
main shaft |
Contour of
product |
Size of main
shaft,shaft hole |
Outlet and
sealing form |
Resolution | Output form | Output signal | Cable | ||||
| G:incremental type | O:megneto-
electricity L:photoelec- tricity |
S:solid shaft | 58:φ58mm | 06:φ6mm
08:φ8mm 10:φ10mm 12:φ12mm 15:φ15mm |
B:side outlet
metal D: rear-outlet metal F:Side outlet plug G:Rear outlet plug |
10,20,50,
60,100, 200,360, 400,500, 600,800, 1000,1024,1 200,2000,20 48,2500,300 0,3600,5000
|
T:push pull output
L:5V drive output A:24V drive output |
1:phase Asignal
2: phase AB signal 3:phase ABZ signal 4:phase ABA/B/ signal 5:phase ABZA/B/Z/ signal |
Default
2m line,For non 2m, labeling is sufficient |
||||
| Line color | Toutput signal | Line color | L/A output signal | 12 pin socket model | |
| brown | VCC | brown | VCC | 2.12 | |
| white | GND | 10,11 | |||
| white | GND | ||||
| green | A phase | 5 | |||
| green | A phase | gray | B phase | 8 | |
| blue | Z phase | 3 | |||
| gray | B phase | ||||
| yellow | Aphase | 6 | |||
| blue | Z phase | pink | Bphase | 1 | |
| red | Zphase | 4 | |||
| shield | F ·G | ||||
| shield | F ·G | F ·G |
push pull output
long line drive output
