| G | 0 | H | 38 | 01 | 1000 T | 3 | 0.7M | ||||||
| Category of
product |
Type of product | Form of
main shaft |
Contour of
product |
Size of main shaft,shaft hole | Outlet and
sealing form |
Outline structure | Resolution | Output form | 输出信号
Outputsignal |
电缆线 Cable | |||
| G:incremental
type |
megneto- electricity | H:semi-
hollow shaft |
38:φ38mm | 口：φ8mm | A:rubber wire
protection sleeve |
01:outline
structure1 |
10,20,50,
60,100, 200360, 400,500, 600,800, 1000,1024, 1200,2000, 2048,2500, 3000,3600, 4096等 |
C:open collector output
F:complementary output L:5V drive output |
1:phaseAsignal
2:phase AB signal 3:phase ABZsignal 4:phase ABA/B/ signal 5: phase ABZA/B/Z/ signal |
Default
0.7m line,For non 0.7m, labeling is sufficient |
|||
| Line color | C/F output signal | – | Line color | Loutput signal |
| red | VCC | red | VCC | |
| black | GND | |||
| black | GND | |||
| green | A phase | |||
| green | A phase | white | B phase | |
| yellow | Z phase | |||
| white | B phase | |||
| blue | Aphase | |||
| yellow | Z phase | gray | Bphase | |
| orange | Z phase | |||
| shield | F ·G | |||
| shield | F ·G |
complementary output/NPN collector open circuitoutput/push pull output
long line drive output
