| G | 0 | S | 50 | 06 | B | – | 1000 | – | C | 3 | 2M | |
| Category of
product |
Type of product | Form of
main shaft |
Contour of
product |
Size of main
shaft,shaft hole |
Outlet and
sealing form |
Resolution | Output form | Output signal | Cable | |||
| G:ncremental type | O:megneto-
electricity |
S:solid shaft | 50:φ50mm | 06:φ6mm | B:Diagonal
outlet |
10,20,50,
60,100, 200360, 400,500, 600,800, 1000,1024,1 200,2000,20 48,2500,300 0,3600,4096 |
C:open collector output
F:complementary output L:5V drive output |
1:phase Asignal
2:phase AB signal 3:phase ABZ signal 4:phase ABA/B/ signal 5:phase ABZA/B/Z/ signal |
Default
2m line,For non 2m, labeling is sufficient |
Line color |
C/F output signal |
– |
Line color |
L/Aoutput signal |
| brown | VCC | brown | VCC | |
| blue | GND | |||
| blue | GND | |||
| black | A phase | |||
| black | A phase | white | B phase | |
| orange | Z phase | |||
| white | B phase | |||
| black red | Aphase | |||
| orange | Z phase | white red | Bphase | |
| orange red | Z phase | |||
| shield | F ·G | |||
| shield | F ·G |
complementary output/NPN collector open circuit output
long line drive output
