Incremental Encoder

GOS58 Rotary Encoder φ58mm | 24V Long-Distance OEM Encoder

Industrial 58mm rotary encoder for automation and semi-automatic applications. Dustproof bearing, selectable shaft sizes, 24V linear drive output for 150m long-distance transmission.

Request a Quote

Description

Product Model And Meaning

G

0

s

58

□

B

1000

A

6

2M

Category of

product

Type of product

Form of

main shaft

Contour of product

Size of main

shaft,shaft hole

Outlet and

sealing form

Resolution

Output form

Output signal

Cable

G:incremental type

0:megneto-

electricity

L:photoelec-

tricity

S:solid shaft

58:φ58mm

06:φ6mm

08:φ8mm

10:10mm

12:φ12mm

15:φ15mm

B:side outlet

metal

D:rear-outlet

metal

F:Side outlet

plug

G:Rear outlet

plug

10,20,50,

60,100,

200,360,

400,500,

600,800,

1000,1024,1

200,2000,20

48,2500,300

0,3600,5000

T:push pull output

L:5V drive output

A:24V drive output

1:phaseAsignal

2:phase AB signal

3:phase ABZ signal

4:phase ABA/B/ signal

5:phase ABZA/B/Z/ signal

Default

2m

lne,For

non 2m,

labeing is

sufficient

Wiring Table

Line color	Toutput signal	Line color	L/A output signal	12 pin socket model
red	VCC	red	VCC	2.12
		black	GND	10,11
black	GND
		green	A phase	5
green	A phase	white	B phase	8
		yellow	Z phase	3
white	B phase
		blue black	Aphase	6
yellow	Z phase	white black	Bphase	1
		yellow black	Zphase	4
shield	F ·G
		shield	F ·G	F ·G
