CY7 High-Frequency Counter | Industrial Automation OEM Device
Precision CY7 high-frequency counter for automation, measurement, and industrial control. Compact, reliable, suitable for machine monitoring and B2B OEM integration. We support OEM/ODM and offer wholesale prices to B2B customers and distributors.
The Industrial Automation OEM Device is a precision CY7 high frequency counter designed for reliable signal measurement in industrial and commercial environments. It accurately captures and displays high‑speed pulse and frequency signals, making it ideal for automation control systems, process monitoring, and test equipment integration.
This compact OEM device supports flexible configuration and can be embedded into larger systems used by electrical contractors, machinery integrators, and factory automation providers. It is well suited for applications such as motor speed monitoring, PLC synchronization, encoder feedback validation, and industrial metering.
Product Model And Significance
| CY |  | 6 | □ | 2 | R | -485 | ||
| CY7 series high-frequency counter | Externalsize(mm) | Number of displayed digit | Apower supply | Alarming output | Controling output | Communication | ||
| 8:48H×96W×97.5L 7:72H×72W×97.5L | 6 digit display | A2:AC/DC 100- 240V D2:DC 24V powered by | 2:2st Road 1:1st Road | R: Relay output | interface 485:with 485 communication interface |
Main Technical Parameters
| Series | CY |
| Display | Double row six digits |
| Power supply | AC/DC100~240V50/60HzorDC24V |
| Allowed range of voltage fluctuation | of the rated voltage(AC power supply) |
| Input frequency of INA,INB | 1Hz、30Hz、300Hz、1KHz、5KHz、10KHz Optional |
| Input pulse width | RESET,1ms or 20ms can be selected |
| Input | voltage input:Input impedance is 5.4KQ,”H”is DC5-30V,and”L”is DC0-2V No voltage input:short-circuit impedance up to 1KQ,residual voltage:up to DC2V,open circuit impedance: up to 100K |
| Time output delay | 0.1~999.9s |
| Contact capacity | NO:AC250V3A load NC:AC250V2A load |
| Memory retention | >10years |
| Power supply of external sensor | DC12V±10%100mA the following |
| Temperature at use | -10℃~50℃(Unfrozen state) |
| Saved temperature | -25℃~65℃(Unfrozen state) |
| Environmental humidity | 35-85%RH |
Input Connection
Mechanical Drawings(mm)
| model | A | B | C | D | E | F | G | H(Min) | J | K(Min) |
| CY7:(72*72) | 72 | 72 | 75 | 4 | 71 | 60 | 67 | 25 | 67 | 25 |
| CY8:(48*96) | 96 | 48 | 75 | 4 | 71 | 38 | 91.5 | 25 | 45 | 25 |
Product Features
- High‑frequency signal measurement
Accurately measures high‑speed pulse and frequency signals for industrial control and automation systems. - OEM‑ready compact design
Small form factor and modular interface, ideal for integration into larger machines, PLCs, and control panels. - Industrial‑grade reliability
Built‑in noise filtering and robust input protection, ensuring stable operation in harsh electrical environments. - Configurable input range and gate time
Supports multiple input ranges and selectable gate times for flexible adaptation to different signal types and applications. - Fast update rate and real‑time display
High‑speed counting and refresh for real‑time monitoring, enabling quick response in process control and test setups. - DIN‑rail or panel‑mount friendly
Designed for easy mounting in control cabinets and industrial enclosures, suitable for electrical contractors and system integrators. - OEM/ODM and low MOQ support
Custom labeling, firmware tweaks, and hardware options available from the original manufacturer, with low minimum order quantities. - Wholesale‑oriented pricing model
Competitive wholesale pricing for distributors, wholesalers, and industrial suppliers sourcing in volume. - Global distribution support
Ready to be supplied through a network of distributors and authorized partners worldwide, with technical documentation and datasheets provided.
Manufactured with robust components, the CY7 counter offers stable performance under varying electrical conditions and is available through our global network of suppliers, wholesalers, and distributors. We support OEM/ODM, custom configurations, low MOQ, and wholesale pricing, making it easy for industrial users, commercial users, and electrical contractors to source exactly what they need for their projects.
