| LX78S | 1000 | 24 | F | 6M | 2G | 2 | |||
| Pulse count(resolution) | voltage | Output form | Measuring stroke | Cable length
direction |
Pulling style | ||||
| 1000:1000BM(0.2)
2000:2000BM(0.1) 2500:2500BM(0.08) 5000:5000BM(0.04) Other |
05:5V
12:12V 24:24V 526:5-26V |
C:open collector output
F:complementary output T:push pull output L:5V drive output A:24V driveoutput |
2G:2-meter cable
side outlet 2E:2-meter cable rear outlet 2-meter standard cable configuration Optional length |
1:Cylindrical shape
2:Circular ring shape
3:Zipper style
4:Lock buckle type
|
| Line color | C/F/Toutput signal | Line color | L/A output signal | |
| red | VCC | red | VCC | |
| black | GND | |||
| black | GND | |||
| green | A phase | |||
| green | A phase | white | B phase | |
| yellow | Z phase | |||
| whith | B phase | |||
| brown | Aphase | |||
| yellow | Z phase | gray | Bphase | |
| orange | Zphase | |||
| shield | F ·G | |||
| shield | F ·G |
| Measurement
stroke
|
0-5mm | Hub circumference
|
300mm |
| Shell material | Imported aluminum alloy,surface anti- static interference,non-conductive | Duration | More than 2 million times |
| Steel wire rope | 0.6mm high flexibility imported coated steel wire rope | Stay wire at outlet | 20N |
| Linear accuiracy | 0.05%FS | Repeated accuracy | 0.01% |
| Resolution | 0.3,0.15,0.12,0.06,
Other |
Maximum round-
trip speed |
2000mm/s |
| Output
signal |
push pull,drive
output |
Working voltage |
5V,12V,24V |
| Number of
pulse |
100-5000 pulses |
Cable length | 2M(standard
configuration), customizable |
|
Protection |
anti-wrong
connection, with overload |
Outlet
direction |
Radial(standard);axial |
